Flange Mounted Double Sheave Fairleads
Product No.
|
Max
Wire
Size
(inch)
|
Wire
Breaking
Strength
(1bs)
|
Sheave
Tread
Dia
(inch)
|
All Measurements(inch)
|
Weight
(1bs)
|
|
A
|
B
|
C
|
D
|
E
|
F
|
|
BMMMEHSFD-001
|
3/4
|
58,800
|
8 1/4
|
22 7/16
|
16
|
21
|
8 3/8
|
9
|
4 1/2
|
266
|
BMMMEHSFD-002
|
1
|
103,400
|
9 3/4
|
26 7/16
|
17
|
23 1/2
|
10 3/8
|
11
|
5 5/8
|
379
|
BMMMEHSFD-003
|
1 1/4
|
159,800
|
11 1/4
|
28 11/16
|
18 3/4
|
27 1/2
|
10 5/8
|
11 3/4
|
6 5/16
|
585
|
BMMMEHSFD-004
|
1 1/2
|
228,000
|
14 1/4
|
36 1/8
|
25
|
35 5/8
|
13 3/4
|
16
|
8 1/2
|
1212
|
BMMMEHSFD-005
|
1 3/4
|
266,000
|
18 1/2
|
43 1/8
|
27
|
46
|
16
|
18
|
9 1/2
|
1799
|
BMMMEHSFD-006
|
2
|
344,000
|
20
|
48
|
30
|
47 1/2
|
17 3/4
|
20
|
12
|
2160
|
BMMMEHSFD-007
|
2 1/4
|
494,000
|
24 7/8
|
54 7/8
|
35 1/2
|
59 3/4
|
22 1/4
|
24
|
13
|
4113
|
BMMMEHSFD-008
|
2 1/2
|
524,000
|
30
|
61
|
39
|
70 5/8
|
24 1/4
|
26
|
14 1/2
|
5330
|
BMMMEHSFD-00
|
3
|
818,000
|
44
|
104
|
60
|
105 5/8
|
41
|
39 1/2
|
26 1/2
|
16090
|
BMMMEHSFD-010
|
3
|
818,000
|
55 1/2
|
117
|
60
|
130 5/8
|
41
|
39 1/2
|
26 1/2
|
18500
|
|
