Double Horizontal Lead Sheave

Product No.

Sheave
Diameter (inch)

Wire Rope
Size (inch)

Safe Work
Load (pounds)

Dimensions (inch)

A

B

C

D

E

F

G

BMMMEHSDH-001

6

1∕2

4000

15 1∕2

5

14 1∕2

6

7∕16

2 3∕4

1 1∕8

BMMMEHSDH-002

8

5∕8

8000

6 3∕4

6 3∕4

18 3∕4

8

9∕16

3 1∕4

1 3∕8

BMMMEHSDH-003

10

3∕4

12000

8 1∕2

8 1∕2

23

10

11∕16

3 3∕4

1 3∕4

BMMMEHSDH-004

14

7∕8

20000

11 1∕2

11 1∕2

21

13 1∕2

13∕16

2 1∕4

2 1∕4
