Six Roller Fairlead
Six Roller Fairlead Drawing
Main Dimensions
|
Product No.
|
a
(mm)
|
b
(mm)
|
c
(mm)
|
d
(mm)
|
e
(mm)
|
f
(mm)
|
h
(mm)
|
i
(mm)
|
k
(mm)
|
l
(mm)
|
m
(mm)
|
n
(mm)
|
|
BMMMERFSI-001
|
180
|
100
|
208
|
80
|
710
|
914
|
465
|
80
|
130
|
620
|
356
|
255
|
BMMMERFSI-002
|
230
|
130
|
258
|
100
|
878
|
1132
|
575
|
100
|
170
|
778
|
446
|
315
|
BMMMERFSI-003
|
250
|
130
|
308
|
120
|
998
|
1272
|
655
|
120
|
210
|
878
|
506
|
375
|
BMMMERFSI-004
|
280
|
160
|
328
|
140
|
1136
|
1420
|
730
|
120
|
248
|
996
|
576
|
432
|
BMMMERFSI-005
|
300
|
160
|
398
|
180
|
1314
|
1678
|
855
|
140
|
326
|
1154
|
676
|
549
|
BMMMERFSI-006
|
320
|
180
|
505
|
245
|
1596
|
1916
|
1045
|
180
|
460
|
1396
|
830
|
750
|
BMMMERFSI-007
|
400
|
250
|
583
|
300
|
1936
|
2400
|
1260
|
200
|
568
|
1716
|
1016
|
912
|
Product No.
|
Rated
Towing
Pull
|
Rope
Φ
|
Breaking
Strength
of Wire
|
Wire
Size
(mm)
|
Weight
KG
|
KG①
|
KG②
|
BMMMERFSI-001
|
20KN
|
-12mm
|
150KN
|
12
|
100
|
150
|
BMMMERFSI-002
|
30KN
|
-16mm
|
220KN
|
16
|
170
|
210
|
BMMMERFSI-003
|
50KN
|
-20mm
|
350KN
|
20
|
390
|
460
|
BMMMERFSI-004
|
80KN
|
-24mm
|
500KN
|
24
|
665
|
800
|
BMMMERFSI-005
|
120KN
|
-32mm
|
800KN
|
32
|
700
|
920
|
BMMMERFSI-006
|
200KN
|
-40mm
|
1150KN
|
40
|
1300
|
1550
|
BMMMERFSI-007
|
320KN
|
-48mm
|
1750KN
|
48
|
2550
|
3100
|
|
