Double Bollards VIS 1

Date:2020-06-12 Click:372 Share to:

Double Bollards VIS 1

Double Bollards VIS 1 Double Bollards VIS 1 Drawing
Product No.	Type	F	Dimension(mm)								Weight(kg)
Product No.	Type	F	A	B	C	D	E	F	G	H	Weight(kg)
BMDM-DBVIS-001	100	5	600	210	310	114	350	145	100	65	36
BMDM-DBVIS-002	150	10	800	260	385	168	500	205	100	90	59
BMDM-DBVIS-003	200	15.5	950	330	460	219	600	255	100	115	98
BMDM-DBVIS-004	230	17	1030	350	470	244	680	300	100	120	113
BMDM-DBVIS-005	250	20	1150	370	520	273	750	320	110	130	135
BMDM-DBVIS-006	300	28	1350	420	597	324	900	370	110	155	210
BMDM-DBVIS-007	350	32	1500	470	657	356	1000	405	110	175	328
BMDM-DBVIS-008	400	40	1650	540	740	406	1100	450	125	200	418
BMDM-DBVIS-009	450	54	1800	600	790	457	1200	510	125	215	499
BMDM-DBVIS-010	500	60	1950	650	840	508	1300	560	125	230	586
BMDM-DBVIS-011	550	68	2100	700	890	559	1400	610	125	250	684
BMDM-DBVIS-012	600	80	2270	770	945	612	1500	660	125	270	900
