Dock Single Bollard （J-Type Bollard ）

Dock Single Bollard （J-Type Bollard ）

Dock Single Bollard （J-Type Bollard ）Drawing

Product No.:BMDM-JDSB-001

Single Bitt Bollard

Bolts Qty

Capacity (Tonnes)

Dimensions(mm)

A

B

C

D

E

F

G

H

4

10

180

120

240

190

25

140

180

25

4

15

215

150

290

220

25

160

220

35

4

20

280

200

360

260

25

200

280

35

4

15

290

150

290

220

25

160

220

35

6

50

460

230

460

380

40

244

340

50
