Double Stage Centrifugal High Pressure Fire Pump

Date:2020-06-09 Click:395 Share to:

Double Stage Centrifugal High Pressure Fire Pump

It has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade, forest fire brigade, towns, rural areas, the mining industry and obligation fire brigade.

Technical parameters:

Device dimension L×W×H: 750×610×650mm;

Pump Inlet dia.: Φ80mm;

Pump outlet dia.: Φ65mm;

Dry Weight: ≤96kg;

Maximum power output : 27Hp/3600r/min;

Starting method : manual start / electric start;

Max. capacity&pressure: 1200L/min/1.4Mpa

Priming Time : ≤20s;

Suction depth: 9m
