RHZKF 9L/90 air breathing apparatus

Date:2020-06-09  Click:250   Share to:

  • HZKF 9L/90 air breathing apparatus

    RHZKF 9L/90 air breathing apparatus

    Positive pressure air respirator RHZKF is a kind of isolation type breath protection equipment, for entering into oxygen, toxic or harmful gases environment the user with respiratory protection. Normal use, scuba mask the pressure inside the always slightly higher than the outside environment stress, can effectively prevent outside poisonous, harmful gas mask intrusive, ensure users within safe.
    Positive pressure air respirator RHZKF can be widely used in fire fighting, petroleum, chemical industry, metallurgy, electric power, ship, police, public security, etc.
    Positive pressure air respirator standards comply with the GA124-2004 "formal pressure air respirator" standards
    Positive pressure air respirator were China classification society (CCS) classification product certificate
    Positive pressure air respirator gas cylinders can choose 3 liters 6.8 litres of 9 liters carbon fiber composite cylinder and 6 litres cylinder (Marine) configurations.
    Positive pressure air respirator design can choose economic standard and   comfortable model configuration

    Positive pressure air respirator technical parameters:

    Cylinders volume

    Cylinders work pressure

    Largest gas flow

    Respiratory resistance

    Alarm pressure

    The weight (lightest configuration)

    Reference use time

    exhale

    Breathe in

    3.0L

    ≤30MPa

    ≥1000L/min

    ≤1000Pa

    ≤500Pa

    5.5±0.5M Pa

    6.2KG

    30 minutes

    6.0L

    ≤30MPa

    ≥1000L/min

    ≤1000Pa

    ≤500Pa

    5.5±0.5M Pa

    13.1KG

    60 minutes

    6.8L

    ≤30MPa

    ≥1000L/min

    ≤1000Pa

    ≤500Pa

    5.5±0.5M Pa

    7.5KG

    68 minutes

    9.0L

    ≤30MPa

    ≥1000L/min

    ≤1000Pa

    ≤500Pa

    5.5±0.5M Pa

    9.1KG

    90 minutes
