Pipe Section Bend

It is a non-combustible stone wool pipe section bend for thermal and condensation insulation of pipework in buildings and ships.

It has a reinforced aluminium foil facing and tape in the longitudinal seam which prevents condensation.

Factory produced bends are a very good and fast insulation solution for pipe elbows.

Product No.	BMMDEDPPB001
Dimension	Dimensions
	Thickness	Inner Diameter
	20 - 50 mm	22 - 114
Fire properties	Reaction to Fire
	Essential characteristics	Performance
	Reaction to Fire	A2L - s1, d0
	Other Fire Properties
	Description	Value
	Combustibility	Base product non-combustible
Thermal properties	Thermal Resistance
	Essential characteristics	Performance
	Thermal Conductivity (declared) in 10 °C, λ10	0.034 W/mK
	Thermal Conductivity (declared) in 50 °C, λ50	0.037 W/mK
	Thermal Conductivity (declared) in 100 °C, λ100	0.044 W/mK
Moisture properties	Water Permeability
	Essential characteristics	Performance
	Water Absorption	≤ 1 kg/m²
	Water Vapour Permeability
	Essential characteristics	Performance
	Water Vapour Diffusion Resistance	MV2

All Material Provided
